| การตรวจจับก๊าซ: | SO2 CO2 CO2 NOX VOC | วิธีการสุ่มตัวอย่าง: | ปั๊มดูด |
|---|---|---|---|
| สี: | สีดำกับสีเขียว | พลัง: | แบตเตอรี่ลิเธียมโพลิเมอร์ |
| น้ำหนัก: | 3700 กรัม | ความชื้น: | 0~95%RH (ไม่มีการควบแน่น) |
| อุณหภูมิ: | -20°C~+50°C | การรับประกัน: | 12 เดือน |
| ข้อกำหนดโพรบ: | จำเป็นต้องเลือกตามอุณหภูมิและความยาวโพรบ | ฟังก์ชั่นการพิมพ์: | เป็นตัวเลือกด้วยเครื่องพิมพ์พกพาภายในหรือเครื่องพิมพ์บลูทู ธ ภายนอก |
| Sensors | Electrochemical (CO, SO2, NOX), Infrared (CO2), PID photo ion principle (VOC) |
|---|---|
| Gas Detected | CO, SO2, NOX, CO2, VOC |
| Measure Range | CO 0-20000PPM; CO2 0~20%VOL; SO2 0~5000PPM; NOX 0~5000PPM; VOC 0~5000PPM |
| Resolution | CO 1PPM; CO2 0.001%VOL; SO2 1PPM; NOX 1PPM; VOC 1PPM |
| Display | Formula, gas concentration data, measurement trend curve, gas curve, battery, time, temperature, humidity, pressure (optional), pump condition, wireless status, printer status, screen shot status |
| Alarm | Buzzer, red LED and alarm status on display, fault alarm, pump abnormal alarm, low battery alarm |
| Data Storage | Independent SD memory card, Max.32G, automatic measurement data recording with customizable time intervals |
| Data Transmission | RS485 signal output, USB interface data transmission, compatible with upper computer software for data download, analysis and printing |
| Print Function (Optional) | Optional internal portable printer or external Bluetooth printer |
| Print Content (Optional) | Text, graphics, barcode, QR code, curves, characters, etc. |
| Charger | Standard Mini-USB charging port with 13V/2A special charger (built-in printer) or 5V/2A universal charger (external printer) |
| Language | Chinese/English |
| Wireless Network (Optional) | Bluetooth |
| Network Frequency | 2.4G high frequency |
| Wireless Transmission Distance | Bluetooth less than 10m |
| Probe Specifications | The smoke environment must be equipped with a high temperature probe gun, resistant to high temperatures of 600°C or 1000°C. Probe lengths available: 0.3m, 0.7m and 1m. |
